2000 - 2003 Mitsubishi Diamante 4 Button Keyless Entry Remote Fob - OUCG8D-522M-A

Programming Instructions:

1. Locate the Data Port under drivers side dashboard usually located to the right of
steering column.

2.Insert keys in ignition and leave in the OFF position.

3. Make sure there are metal contact pins in terminals 1 and 4 and connect the Data
Port terminals 1 and 4 with a suitable jumper wire, leave the jumper wire connected
throughout the programming procedure. Make sure you know which terminals are 1
and 4.

4. Within 10 seconds after connecting the jumper wire, press the Hazard Switch 6 times.
Note: The doors will automatically lock and unlock once at this time indicating that the
system is in the programming mode.

5. Press the LOCK button on the remote to be registered three times within 10 seconds.
Upon successful programming, the door will lock and unlock once.

6. Repeat step 5 with up to 4 remotes (including any existing remotes) within one
minute. After completing each programming, the doors will lock and unlock once.

7. Disconnect the programming wire and remove the keys from the ignition.
