If you are not 100% satisfied with your product for any reason, you may return the product within 180 days of ordering for a replacement. Please see our return policy for further information.
SKU | 7487 |
---|---|
FCC Number | HYQ4AA |
OE Part # | 13584500 13508406 |
Support | Your purchase gives you 100% free e-mail and phone technical support from our expert staff. |
Programming Information | This remote comes with self programming instructions which you can view under the "Programming Instructions" tab above. |
Product Condition | Refurbished |
Programming Instructions | Only RKE transmitters programmed to the vehicle will work. If a transmitter is lost or stolen, a replacement can be purchased and programmed. The vehicle can be reprogrammed so that lost or stolen transmitters no longer work. Any remaining transmitters will need to be reprogrammed. Each vehicle can have up to eight transmitters matched to it. Programming with Recognized Transmitters A new transmitter can be programmed to the vehicle when there are TWO recognized transmitters. To program, the vehicle must be off and all of the transmitters, both currently recognized and new, must be with you.
2. Insert the vehicle key of the new transmitter into the key lock cylinder on the outside of the driver door and turn the key to the unlock position five times within 10 seconds. The Driver Information Center (DIC) displays READY FOR REMOTE #2, 3, 4 or 5. 3. Remove the two recognized transmitters from the center console front cupholder. 4. Place the new transmitter in the front cupholder 5. Press ENGINE START/STOP. When the transmitter is learned, the DIC will show that it is ready to program the next transmitter. 6. Remove the transmitter from the transmitter pocket and press UNLOCK. To program additional transmitters, repeat Steps 4–6. When all additional transmitters are programmed, press and hold ENGINE START/STOP for 12 seconds to exit programming mode. Programming without Recognized Transmitters If TWO currently recognized transmitters are not available, follow this procedure to program up to eight transmitters. This feature is not available in Canada. This procedure will take approximately 30 minutes to complete. The vehicle must be off and all of the transmitters to be programmed must be with you. 1. Insert the vehicle key of the transmitter into the key lock cylinder on the outside of the driver door and turn the key to the unlock position five times within 10 seconds. The Driver Information Center (DIC) displays REMOTE LEARN PENDING, PLEASE WAIT. 2. Wait for 10 minutes until the DIC displays PRESS ENGINE START BUTTON TO LEARN and then press ENGINE START/STOP. The DIC will again show REMOTE LEARN PENDING, PLEASE WAIT. 3. Repeat Step 2 two additional times. After the third time, all previously known transmitters will no longer work with the vehicle. Remaining transmitters can be relearned during the next steps. The DIC display should now show READY FOR REMOTE # 1. 4. Place the new transmitter in the front cupholder. 5. Press ENGINE START/STOP. When the transmitter is learned, the DIC will show that it is ready to program the next transmitter. 6. Remove the transmitter from the cupholder and press UNLCOK. To program additional transmitters, repeat Steps 4–6. When all additional transmitters are programmed, press and hold ENGINE START/STOP for 12 seconds to exit programming mode. |
msrp | 178.79 |
